| MODEL | d | D1 | D2 | L1 | L2 | G |
| HSK32A HC06 L80 | 6 | 26 | 40 | 29 | 27 | M5 |
| HSK32A HC08 L80 | 8 | 28 | 40 | 29 | 27 | M6 |
| HSK32A HC10 L85 | 10 | 30 | 40 | 35 | 32 | M6 |
| HSK32A HC12 L90 | 12 | 32 | 40 | 40 | 37 | M6 |
| HSK40A HC06 L70 | 6 | 26 | 34 | 36 | 27 | M5 |
| HSK40A HC08 L70 | 8 | 28 | 34 | 36 | 27 | M6 |
| HSK40A HC10 L75 | 10 | 30 | 34 | 42 | 32 | M6 |
| HSK40A HC12 L80 | 12 | 32 | 34 | 48 | 37 | M6 |
| HSK50A HC06 L70 | 6 | 26 | 40 | 28 | 27 | M5 |
| HSK50A HC08 L70 | 8 | 28 | 40 | 28 | 27 | M6 |
| HSK50A HC10 L80 | 10 | 30 | 40 | 39 | 32 | M8x1 |
| HSK50A HC12 L85 | 12 | 32 | 40 | 44 | 37 | M10x1 |
| HSK50A HC14 L85 | 14 | 34 | 40 | 43 | 37 | M10x1 |
| HSK50A HC16 L90 | 16 | 38 | 53 | 30 | 42 | M12x1 |
| HSK50A HC18 L90 | 18 | 40 | 57 | 30 | 42 | M12x1 |
| HSK50A HC20 L90 | 20 | 42 | 60 | 29 | 42 | M16x1 |
| HSK63A HC06 L70 | 6 | 26 | 50 | 23.5 | 30 | M5 |
| HSK63A HC08 L70 | 8 | 28 | 50 | 24 | 30 | M6 |
| HSK63A HC10 L80 | 10 | 30 | 50 | 34.5 | 34 | M8x1 |
| HSK63A HC12 L85 | 12 | 32 | 50 | 39.5 | 39 | M10x1 |
| HSK63A HC14 L85 | 14 | 34 | 50 | 40 | 37 | M10x1 |
| HSK63A HC16 L90 | 16 | 38 | 50 | 45.5 | 42 | M10x1 |
| HSK63A HC18 L90 | 18 | 40 | 50 | 47 | 42 | M12x1 |
| HSK63A HC20 L90 | 20 | 42 | 50 | 46.5 | 44 | M16x1 |
| HSK63A HC25 L120 | 25 | 57 | 62 | 59 | 50 | M16x1 |
| HSK63A HC32 L125 | 32 | 64 | - | - | 54 | M16x1 |
| HSK63A HC06 L150 | 6 | 26 | 50 | 103.5 | 30 | M5 |
| HSK63A HC08 L150 | 8 | 28 | 50 | 104 | 30 | M6 |
| HSK63A HC10 L150 | 10 | 30 | 50 | 104.5 | 34 | M8x1 |
| HSK63A HC12 L150 | 12 | 32 | 50 | 104.5 | 39 | M10x1 |
| HSK63A HC14 L150 | 14 | 34 | 50 | 105.5 | 42 | M12x1 |
| HSK63A HC16 L150 | 16 | 38 | 50 | 105.5 | 42 | M12x1 |
| HSK63A HC18 L150 | 18 | 40 | 50 | 105.5 | 42 | M12x1 |
| HSK63A HC20 L150 | 20 | 42 | 50 | 106 | 44 | M16x1 |
| HSK63A HC25 L150 | 25 | 57 | 62 | 89 | 50 | M16x1 |
| HSK63A HC32 L150 | 32 | 64 | 70 | 88 | 54 | M16x1 |
| HSK63A HC06 L200 | 6 | 26 | 50 | 103.5 | 30 | M5 |
| HSK63A HC08 L200 | 8 | 28 | 50 | 104 | 30 | M6 |
| HSK63A HC10 L200 | 10 | 30 | 50 | 104.5 | 34 | M8x1 |
| HSK63A HC12 L200 | 12 | 32 | 50 | 104.5 | 39 | M10x1 |
| HSK63A HC14 L200 | 14 | 34 | 50 | 105.5 | 42 | M12x1 |
| HSK63A HC16 L200 | 16 | 38 | 50 | 105.5 | 42 | M12x1 |
| HSK63A HC18 L200 | 18 | 40 | 50 | 105.5 | 42 | M12x1 |
| HSK63A HC20 L200 | 20 | 42 | 50 | 106 | 44 | M16x1 |
| HSK63A HC25 L200 | 25 | 57 | 62 | 152 | 50 | M16x1 |
| HSK63A HC32 L200 | 32 | 64 | 70 | 152 | 54 | M16x1 |
| HSK80A HC12 L85 | 12 | 32 | 50 | 40 | 37 | M10x1 |
| HSK80A HC20 L90 | 20 | 42 | 50 | 52 | 42 | M16x1 |
| HSK80A HC32 L125 | 32 | 64 | 75 | 63 | 55 | M16x1 |
| HSK100A HC06 L75 | 6 | 26 | 50 | 25.5 | 30 | M5 |
| SHK100A HC08 L75 | 8 | 28 | 50 | 26 | 30 | M6 |
| HSK100A HC10 L90 | 10 | 30 | 50 | 41.5 | 34 | M8x1 |
| HSK100A HC12 L95 | 12 | 32 | 50 | 47 | 37 | M10x1 |
| HSK100A HC14 L95 | 14 | 34 | 50 | 47 | 37 | M10x1 |
| HSK100A HC16 L100 | 16 | 38 | 50 | 52.5 | 42 | M12x1 |
| HSK100A HC18 L100 | 18 | 40 | 50 | 53 | 42 | M12x1 |
| HSK100A HC20 L105 | 20 | 42 | 60 | 54.5 | 44 | M16x1 |
| HSK100A HC25 L110 | 25 | 57 | 70 | 60 | 50 | M16x1 |
| HSK100A HC32 L110 | 32 | 64 | 70 | 62 | 54 | M16x1 |
| HSK100A HC06 L150 | 6 | 26 | 50 | 100 | 30 | M5 |
| HSK100A HC08 L150 | 8 | 28 | 50 | 100.5 | 30 | M6 |
| HSK100A HC10 L150 | 10 | 30 | 50 | 101 | 34 | M8x1 |
| HSK100A HC12 L150 | 12 | 32 | 50 | 101.5 | 39 | M10x1 |
| HSK100A HC14 L150 | 14 | 34 | 50 | 105.5 | 42 | M12x1 |
| HSK100A HC16 L150 | 16 | 38 | 50 | 105.5 | 42 | M12x1 |
| HSK100A HC18 L150 | 18 | 40 | 50 | 105.5 | 42 | M12x1 |
| HSK100A HC20 L150 | 20 | 42 | 50 | 106 | 44 | M16x1 |
| HSK100A HC25 L150 | 25 | 57 | 70 | 100 | 50 | M16x1 |
| HSK100A HC32 L150 | 32 | 64 | 70 | 102 | 54 | M16x1 |
| HSK100A HC06 L200 | 6 | 26 | 50 | 103.5 | 30 | M5 |
| HSK100A HC08 L200 | 8 | 28 | 50 | 104 | 30 | M6 |
| HSK100A HC10 L200 | 10 | 30 | 50 | 104.5 | 34 | M8x1 |
| HSK100A HC12 L200 | 12 | 32 | 50 | 104.5 | 39 | M10x1 |
| HSK100A HC14 L200 | 14 | 34 | 50 | 105.5 | 42 | M12x1 |
| HSK100A HC16 L200 | 16 | 38 | 50 | 105.5 | 42 | M12x1 |
| HSK100A HC18 L200 | 18 | 40 | 50 | 105.5 | 42 | M12x1 |
| HSK100A HC20 L200 | 20 | 42 | 50 | 106 | 44 | M16x1 |
| HSK100A HC25 L200 | 25 | 57 | 62 | 152 | 50 | M16x1 |
| HSK100A HC32 L200 | 32 | 64 | 70 | 152 | 54 | M16x1 |
| MODEL | d | D1 | D2 | L1 | L2 | G |
| HSK32A HC06 L80 | 6 | 26 | 40 | 29 | 27 | M5 |
| HSK32A HC08 L80 | 8 | 28 | 40 | 29 | 27 | M6 |
| HSK32A HC10 L85 | 10 | 30 | 40 | 35 | 32 | M6 |
| HSK32A HC12 L90 | 12 | 32 | 40 | 40 | 37 | M6 |
| HSK40A HC06 L70 | 6 | 26 | 34 | 36 | 27 | M5 |
| HSK40A HC08 L70 | 8 | 28 | 34 | 36 | 27 | M6 |
| HSK40A HC10 L75 | 10 | 30 | 34 | 42 | 32 | M6 |
| HSK40A HC12 L80 | 12 | 32 | 34 | 48 | 37 | M6 |
| HSK50A HC06 L70 | 6 | 26 | 40 | 28 | 27 | M5 |
| HSK50A HC08 L70 | 8 | 28 | 40 | 28 | 27 | M6 |
| HSK50A HC10 L80 | 10 | 30 | 40 | 39 | 32 | M8x1 |
| HSK50A HC12 L85 | 12 | 32 | 40 | 44 | 37 | M10x1 |
| HSK50A HC14 L85 | 14 | 34 | 40 | 43 | 37 | M10x1 |
| HSK50A HC16 L90 | 16 | 38 | 53 | 30 | 42 | M12x1 |
| HSK50A HC18 L90 | 18 | 40 | 57 | 30 | 42 | M12x1 |
| HSK50A HC20 L90 | 20 | 42 | 60 | 29 | 42 | M16x1 |
| HSK63A HC06 L70 | 6 | 26 | 50 | 23.5 | 30 | M5 |
| HSK63A HC08 L70 | 8 | 28 | 50 | 24 | 30 | M6 |
| HSK63A HC10 L80 | 10 | 30 | 50 | 34.5 | 34 | M8x1 |
| HSK63A HC12 L85 | 12 | 32 | 50 | 39.5 | 39 | M10x1 |
| HSK63A HC14 L85 | 14 | 34 | 50 | 40 | 37 | M10x1 |
| HSK63A HC16 L90 | 16 | 38 | 50 | 45.5 | 42 | M10x1 |
| HSK63A HC18 L90 | 18 | 40 | 50 | 47 | 42 | M12x1 |
| HSK63A HC20 L90 | 20 | 42 | 50 | 46.5 | 44 | M16x1 |
| HSK63A HC25 L120 | 25 | 57 | 62 | 59 | 50 | M16x1 |
| HSK63A HC32 L125 | 32 | 64 | - | - | 54 | M16x1 |
| HSK63A HC06 L150 | 6 | 26 | 50 | 103.5 | 30 | M5 |
| HSK63A HC08 L150 | 8 | 28 | 50 | 104 | 30 | M6 |
| HSK63A HC10 L150 | 10 | 30 | 50 | 104.5 | 34 | M8x1 |
| HSK63A HC12 L150 | 12 | 32 | 50 | 104.5 | 39 | M10x1 |
| HSK63A HC14 L150 | 14 | 34 | 50 | 105.5 | 42 | M12x1 |
| HSK63A HC16 L150 | 16 | 38 | 50 | 105.5 | 42 | M12x1 |
| HSK63A HC18 L150 | 18 | 40 | 50 | 105.5 | 42 | M12x1 |
| HSK63A HC20 L150 | 20 | 42 | 50 | 106 | 44 | M16x1 |
| HSK63A HC25 L150 | 25 | 57 | 62 | 89 | 50 | M16x1 |
| HSK63A HC32 L150 | 32 | 64 | 70 | 88 | 54 | M16x1 |
| HSK63A HC06 L200 | 6 | 26 | 50 | 103.5 | 30 | M5 |
| HSK63A HC08 L200 | 8 | 28 | 50 | 104 | 30 | M6 |
| HSK63A HC10 L200 | 10 | 30 | 50 | 104.5 | 34 | M8x1 |
| HSK63A HC12 L200 | 12 | 32 | 50 | 104.5 | 39 | M10x1 |
| HSK63A HC14 L200 | 14 | 34 | 50 | 105.5 | 42 | M12x1 |
| HSK63A HC16 L200 | 16 | 38 | 50 | 105.5 | 42 | M12x1 |
| HSK63A HC18 L200 | 18 | 40 | 50 | 105.5 | 42 | M12x1 |
| HSK63A HC20 L200 | 20 | 42 | 50 | 106 | 44 | M16x1 |
| HSK63A HC25 L200 | 25 | 57 | 62 | 152 | 50 | M16x1 |
| HSK63A HC32 L200 | 32 | 64 | 70 | 152 | 54 | M16x1 |
| HSK80A HC12 L85 | 12 | 32 | 50 | 40 | 37 | M10x1 |
| HSK80A HC20 L90 | 20 | 42 | 50 | 52 | 42 | M16x1 |
| HSK80A HC32 L125 | 32 | 64 | 75 | 63 | 55 | M16x1 |
| HSK100A HC06 L75 | 6 | 26 | 50 | 25.5 | 30 | M5 |
| SHK100A HC08 L75 | 8 | 28 | 50 | 26 | 30 | M6 |
| HSK100A HC10 L90 | 10 | 30 | 50 | 41.5 | 34 | M8x1 |
| HSK100A HC12 L95 | 12 | 32 | 50 | 47 | 37 | M10x1 |
| HSK100A HC14 L95 | 14 | 34 | 50 | 47 | 37 | M10x1 |
| HSK100A HC16 L100 | 16 | 38 | 50 | 52.5 | 42 | M12x1 |
| HSK100A HC18 L100 | 18 | 40 | 50 | 53 | 42 | M12x1 |
| HSK100A HC20 L105 | 20 | 42 | 60 | 54.5 | 44 | M16x1 |
| HSK100A HC25 L110 | 25 | 57 | 70 | 60 | 50 | M16x1 |
| HSK100A HC32 L110 | 32 | 64 | 70 | 62 | 54 | M16x1 |
| HSK100A HC06 L150 | 6 | 26 | 50 | 100 | 30 | M5 |
| HSK100A HC08 L150 | 8 | 28 | 50 | 100.5 | 30 | M6 |
| HSK100A HC10 L150 | 10 | 30 | 50 | 101 | 34 | M8x1 |
| HSK100A HC12 L150 | 12 | 32 | 50 | 101.5 | 39 | M10x1 |
| HSK100A HC14 L150 | 14 | 34 | 50 | 105.5 | 42 | M12x1 |
| HSK100A HC16 L150 | 16 | 38 | 50 | 105.5 | 42 | M12x1 |
| HSK100A HC18 L150 | 18 | 40 | 50 | 105.5 | 42 | M12x1 |
| HSK100A HC20 L150 | 20 | 42 | 50 | 106 | 44 | M16x1 |
| HSK100A HC25 L150 | 25 | 57 | 70 | 100 | 50 | M16x1 |
| HSK100A HC32 L150 | 32 | 64 | 70 | 102 | 54 | M16x1 |
| HSK100A HC06 L200 | 6 | 26 | 50 | 103.5 | 30 | M5 |
| HSK100A HC08 L200 | 8 | 28 | 50 | 104 | 30 | M6 |
| HSK100A HC10 L200 | 10 | 30 | 50 | 104.5 | 34 | M8x1 |
| HSK100A HC12 L200 | 12 | 32 | 50 | 104.5 | 39 | M10x1 |
| HSK100A HC14 L200 | 14 | 34 | 50 | 105.5 | 42 | M12x1 |
| HSK100A HC16 L200 | 16 | 38 | 50 | 105.5 | 42 | M12x1 |
| HSK100A HC18 L200 | 18 | 40 | 50 | 105.5 | 42 | M12x1 |
| HSK100A HC20 L200 | 20 | 42 | 50 | 106 | 44 | M16x1 |
| HSK100A HC25 L200 | 25 | 57 | 62 | 152 | 50 | M16x1 |
| HSK100A HC32 L200 | 32 | 64 | 70 | 152 | 54 | M16x1 |
